A '50s Stratocaster on the outside, with a modern player's neck and electronics underneath. The body is ash or alder depending on the finish, under an Heirloom nitrocellulose lacquer that comes aged, with a 1-ply parchment pickguard and aged white covers. Three Pure Vintage '57 single-coils give it the right voice for the era.
The neck is where it parts ways with 1957. A quartersawn maple Modern "D" with rolled edges, a 10" to 14" compound radius that stays round near the nut for chords and flattens up high so bends don't choke, and 22 medium jumbo stainless steel frets that won't wear the way nickel does. A tapered heel opens up the top of the neck. The S-1 switch on the volume knob adds the neck pickup into positions 1 and 2, so you get bridge plus neck, and all three together.
For the period neck and hardware, the American Vintage II 1957 Stratocaster uses the same pickups on a 7.25" radius "V" neck. Offered in White Blonde and 3-Color Sunburst, both with a maple fingerboard.
SPECIFICATIONS
BODY
Country of Origin: USA
Body Material: Ash or Alder (by finish)
Body Finish: Heirloom Nitrocellulose Lacquer
Body Shape: Stratocaster
Pickguard: 1-Ply Parchment
Aging: Heirloom
NECK
Neck Material: Maple
Neck Construction: 4-Bolt Standard
Neck Finish: Satin Lacquer
Neck Shape: Modern "D"
Fingerboard Radius: 10" to 14" Compound Radius (254 mm to 355.6 mm)
Fingerboard Material: Maple
Position Inlays: Black Dot
Side Dots: Luminlay
Number of Frets: 22
Fret Size: Medium Jumbo Stainless Steel
Nut Material: TUSQ
Nut Width: 1.685" (42.8 mm)
Scale Length: 25.5" (648 mm)
ELECTRONICS
Bridge Pickup: Pure Vintage '57 Single-Coil Strat
Middle Pickup: Pure Vintage '57 Single-Coil Strat
Neck Pickup: Pure Vintage '57 Single-Coil Strat
Pickup Configuration: SSS
Controls: Master Volume (with S-1 Switch), Tone 1. (Neck/Middle Pickups), Tone 2. (Bridge Pickup)
Switching: 5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and Neck Pickup, Position 5. Neck Pickup
Special Electronics: S-1 Switch Adds Neck Pickup Into Positions 1 and 2
HARDWARE
Bridge: 2-Point Deluxe Synchronized Tremolo with Pop-In Arm
Hardware Finish: Nickel/Chrome
Tuning Machines: Deluxe Cast/Sealed Locking
Pickup Covers: Aged White
Control Knobs: Aged White Soft Touch Knobs
Strap Buttons: Locking
Strings: Fender USA 250L Nickel Plated Steel (.009-.042 Gauges), PN 0730250403
CASE
Case: Deluxe Hardshell Case Included
