Power Output:
8 Ohms: 365W @ 1% THD
4 Ohms: 702W @ 1% THD
Size:
(H x W x D in.) 3.39 x 15.1 x 8
(H x W x D cm) 8.6 x 38.41 x 20.32
Power Amplifier: Class D with Switch‐Mode Power Supply
Pre‐Amp: Low noise, all analog, solid state
Input: ¼” Phone with switchable attenuation and rotary gain control
Input Level Indicator: Signal level and Clip LEDs (green/red)
EQ: 4 Band Switchable
Shelving Bass and Treble with selectable Hi‐Pass frequencies.
Low‐Mid and Hi ‐Mid ‐Variable Gain, Band Pass EQ with selectable frequency / bandwidth options
Master Volume: Rotary Control
Line In: 1/8″ mini jack
Headphone Out: Stereo ¼” Phone jack
Mute Switch: mini toggle
AC Mains: 85‐132V, 195‐264V, 45‐65 Hz, 1000VA (Worldwide usage)
AC Mains Indicator: Blue LED
EFX Loop: Series
Direct Out: 600 Ohm Balanced, XLR, Pre/Post, Ground Lift and Level control
Speaker Output: 1 x Neutrik Combi‐Connectors
Chassis: Aircraft grade aluminum w/removable rubber feet
Rack Ears (Optional)
Weight: 5.2 lbs / 2.37 kg
Warranty: 5 year limited
