The Deluxe Memory Man 1100-TT is Electro-Harmonix's analog Deluxe Memory Man with tap tempo, an expression input and an effects loop built in. The red badge under the Memory Man name on this one reads 1100-TT. If you're looking for the earlier edition, the one with Tap Tempo in that badge, this is the later pedal. EHX discontinued the 1100-TT in 2025, and this one is new.
Delay time runs from 52 ms to 1100 ms, with the analog repeats and modulation the Deluxe Memory Man is known for. Tap the time in with the left footswitch or an external tap switch, and Tap Divide sets the repeats to a dotted eighth, quarter-note triplet, eighth, eighth-note triplet or sixteenth, so a dotted-eighth part stays locked to the song without chasing the Delay knob.
An expression pedal can take over Blend, Rate, Depth, Feedback or Delay. The send and return loop sits on the delayed signal only, so a pedal placed there shapes the repeats and leaves your dry tone alone. True bypass, with EHX's 9.6V power adapter included.
SPECIFICATIONS
SPECS
Circuit: Analog, Analog w/ Digital Control
Delay Time: 52 mS to 1100 mS
Controls: Blend, Gain, Rate, Depth, Feedback, Delay
Tap Divide: dotted eighth, quarter note triplet, eighth note, eighth note triplet, sixteenth note
Expression Modes: Blend, Rate, Depth, Feedback, Delay
Footswitches: Tap, Bypass
Jacks: Input, Output, Send, Return, Exp. Pedal, Tap SW
Effects Loop: Yes
Bypass: True Bypass
Audio: Mono
Power Supply: 9.6VDC-200mA power adapter included
Current Draw: 200mA
Dimensions (in): 5.75 x 4.75 x 2.5
UPC: 683274011790
