The M-7 Johnny Marr is a seven-string on Martin's M-14 Fret body, the 0000 size Martin calls a Grand Auditorium. The seventh string is an octave G, so the G course is doubled as it would be on a 12-string while the other five stay single.
The rest follows the M-6 Johnny Marr: East Indian rosewood and spruce with an Antique Toner gloss top, scalloped X bracing, a Full Thickness genuine mahogany neck with Standard Taper, and Style 28 inlays on an ebony board. The bridge is a modern pyramid 7 string design in ebony with a compensated bone saddle, an LR Baggs Anthem is fitted, and it comes in a hardshell case.
For the six-string version, look at the M-6 Johnny Marr. For every course doubled, the 12-strings in this catalogue are the HD12-28 and the Grand J-16E 12-String.
SPECIFICATIONS
BODY
Country of Origin: USA (Nazareth, Pennsylvania)
Body Size: M-14 Fret (0000-14 Fret)
Construction: Dovetail Neck Joint
Back Material: East Indian Rosewood
Side Material: East Indian Rosewood
Back and Sides Finish: Gloss
Back and Sides Color: Natural
Back Purfling/Strip: Style 28
Back Inlay Material: Multi-Stripe
Bracing Pattern: X-Brace
Brace Shape: Scalloped
Brace Material: Spruce
Brace Size: 5/16"
Top Material: Spruce
Finish Top: Gloss
Top Color: Antique Toner
Top Inlay Material: Multi-Stripe
Binding: Antique White
Pickguard: Faux Tortoise
Rosette: Style 28 Multi-Stripe
NECK
Neck Shape: Full Thickness
Neck Taper: Standard Taper
Neck Material: Geniune Mahogany
Neck Color: Dark Mahogany
Finish Neck: Gloss
Scale Length: 25.4"
Number of Frets Total: 20
Neck Joins Body At: 14th Fret
Heelcap: Antique White
Fingerboard Material: Ebony
Fingerboard Width at 12th Fret: 2 1/8''
Fingerboard Width at Nut: 1 11/16''
Fingerboard Inlay Style: Style 28
Fingerboard Inlay Material: Mother of Pearl
Side Dots: White
Headstock Shape: Solid with Square Taper and Diamond
Headplate Material: East Indian Rosewood
Headplate Logo Style: Script Old Style Overlay
Pleked: Yes
ELECTRONICS
Electronics: LR Baggs Anthem
HARDWARE
Bridge Material: Ebony
Bridge Style: Modern Pyramid 7 String - Drop in Saddle
Bridge String Spacing: 2 1/8''
Bridge Pin Material: White Plastic
Bridge Pin Dots: Faux Tortoise
Saddle: Compensated Bone
Saddle Radius: 16"
Tuning Machines: Chrome Enclosed Gear
Knob: Small
Nut Material: Bone
CASE
Case: Hardshell
