Hombre is Suhr's take on the Brownface circuit: a 1x12 combo with Normal and Bright channels, each with Volume and Tone only, two 6V6s for about 18 watts and a 5AR4 rectifier. The transformers are custom made in the USA on paper bobbins, and the component layout was reworked to keep noise down.
The tremolo modulates the power tubes' bias, and its depth moves with your playing. It sits back when the amp is pushed or you hit harder, and comes forward as the note decays. A single-button footswitch for it is in the box, and there is no standby switch to manage.
The cabinet is box-jointed pine with a floating baffle, in Vintage Palomino Nubtex with Tan/Brown Wheat grill cloth, carrying a 12" Celestion V-Type, at 33lbs all in. The Hombre Head is the same amp at 18.6lbs, with the Hombre 2x12 Cabinet as its partner. The combo is the one we would point most players to, since it is the whole amp in one light piece.
SPECIFICATIONS
AMPLIFIER
Country of Origin: United States
Configuration: 1x12 Combo
Wattage: 18 watts
Voltage: Available in 100V, 120V, 230V, and 240V configurations
Effects: Foot-switchable Tube-Biased Tremolo (Active In Normal & Bright Inputs)
Transformers: Custom made, wound on paper bobbins, made in the USA
TUBES
Preamp Tubes: 3x 12AX7
Power Tubes: 2x 6V6
Rectifier Tube: 1x 5AR4
CONTROLS
Controls: Volume, Tone (Normal). Volume, Tone (Bright). Speed, Intensity (Tremolo)
Power Switch: On/Off (no standby switch)
CONNECTIONS
Inputs: 2x Normal, 2x Bright (HI and LO on each channel)
Speaker Outputs: 2
Operating Impedance: 8Ω (safe to operate at 4Ω or 16Ω - see user guide)
Tremolo Footswitch: 1/4" latching tip-ground
Fuse: 100/120V: 2.0A Slow-Blow, 230/240V: 1.0A Slow-Blow
CABINET
Cabinet Material: Box Jointed Pine
Baffle: Floating
Tolex: Vintage Palomino Nubtex
Grill Cloth: Tan/Brown Wheat
SPEAKERS
Speaker: 12" Celestion® V-Type
DIMENSIONS
Dimensions: 20.84" W x 18.1" H x 9.52" D
Weight: 33lbs
ACCESSORIES
Foot-switch: Includes single button foot-switch for tremolo activation
